Applicable materials:Removal of iron in non-magnetic materials on belt conveyor, vibrating feeder and blanking chute.
Application scope:Removal of iron in non-magnetic materials on belt conveyor, vibrating feeder and blanking chute.
Applicable scope of Magnetic Separator: removal of iron in non-magnetic materials on belt conveyor, vibrating feeder and blanking chute.
With its strong magnetic field, ferrous metals are attracted from your non-ferrous conveyed materials, collected on the self cleaning magnetic separator belt.The moving belt carries the collected metal outside of the magnetic field where it is then released beyond the product flow.
| Model | Belt?width Adaptive (mm) |
Suspension Height?Rated (mm) |
Magnetic Intensity SHR?(mT) |
Material Thickness (mm) |
Motor Power (kw) |
Belt?Velocity (m/s) |
Weight (kg) |
Overall?Dimensions (L×W×H)?(mm) |
||
| RCYD-5 | 500 | 150 | 60 | 80 | 1.5 | 4.5 | 750 | 1900 | 735 | 935 |
| RCYD-6.5 | 650 | 200 | 70 | 150 | 2.2 | 4.5 | 1200 | 2165 | 780 | 1080 |
| RCYD-8 | 800 | 250 | 70 | 200 | 2.2 | 4.5 | 1400 | 2350 | 796 | 1280 |
| RCYD-10 | 1000 | 300 | 70 | 250 | 3.0 | 4.5 | 2120 | 2660 | 920 | 1550 |
| RCYD-12 | 1200 | 350 | 70 | 300 | 4.0 | 4.5 | 3350 | 2900 | 970 | 1720 |
| RCYD-14 | 1400 | 400 | 70 | 350 | 4.0 | 4.5 | 4450 | 3225 | 1050 | 1980 |
